DVB-S2X Explained

Satellite bandwidth is expensive. Every megahertz of transponder capacity on a geostationary satellite represents a physical resource that cannot be manufactured on demand — it is constrained by orbital slot assignments, frequency coordination, and the satellite's payload design. In this environment, the efficiency with which bits are packed into each hertz of spectrum directly determines the economics of every satellite service, from enterprise VSAT to broadcast distribution to maritime broadband.

The waveform standard that governs how those bits are encoded, modulated, and transmitted over the satellite link has evolved through three generations. DVB-S, published in 1994, established the baseline for digital satellite transmission with QPSK modulation and convolutional coding. DVB-S2, ratified in 2003, introduced LDPC forward error correction and adaptive coding and modulation (ACM), roughly doubling spectral efficiency over its predecessor. DVB-S2X, published in 2014 as an extension of DVB-S2, refines and extends the standard with finer MODCOD granularity, higher-order modulation, tighter roll-off factors, and wideband carrier support — delivering incremental but operationally significant gains in spectral efficiency across a wider range of link conditions.

This article provides an engineering-level explanation of what DVB-S2X adds to DVB-S2, why those additions matter in real network deployments, and what trade-offs operators and engineers should consider. For foundational treatment of modulation, coding, and MODCOD selection, see our Satellite Modulation and Coding Guide. For ACM operation and loop design, see our ACM guide.

---

What Is DVB-S2?

Before examining DVB-S2X, it is important to understand the foundation it extends. DVB-S2 (ETSI EN 302 307-1), ratified in 2003 and widely deployed from the mid-2000s onward, represented a major leap in satellite transmission efficiency over the original DVB-S standard.

DVB-S2 introduced several key capabilities:

• LDPC + BCH FEC: DVB-S2 replaced the convolutional + Reed-Solomon coding of DVB-S with a concatenated LDPC (Low-Density Parity-Check) outer code and BCH (Bose-Chaudhuri-Hocquenghem) inner code. This coding scheme operates approximately 0.7–1.0 dB from the Shannon limit, delivering substantially better error correction performance for the same code rate. The result was the ability to use higher-order modulation schemes that would have been impractical with the older FEC technology.

• 28 MODCODs: DVB-S2 defined 28 modulation and coding combinations spanning QPSK, 8PSK, 16APSK, and 32APSK modulations with code rates from 1/4 to 9/10. This range covered spectral efficiencies from approximately 0.49 bit/s/Hz (QPSK 1/4) to 4.45 bit/s/Hz (32APSK 9/10), providing a wide operating range for different link conditions.

• Three roll-off factors: DVB-S2 specified roll-off values of α = 0.35, 0.25, and 0.20, determining the excess bandwidth beyond the Nyquist minimum. The tightest roll-off (0.20) reduced the occupied bandwidth of a carrier by approximately 12.5% compared to the widest (0.35), a meaningful saving on bandwidth-limited transponders.

• ACM, VCM, and CCM: DVB-S2 introduced Adaptive Coding and Modulation as a standard capability, enabling the transmitter to change MODCOD on a frame-by-frame basis in response to real-time signal quality measurements. This feature alone delivered 2–4× average throughput improvements over fixed CCM operation on links subject to rain fade and other variable impairments.

DVB-S2 was a major success and remains the dominant satellite waveform standard globally. However, as HTS deployments expanded and operators sought every possible efficiency improvement, several limitations of DVB-S2 became apparent:

Coarse MODCOD spacing. The gaps between adjacent DVB-S2 MODCODs — typically 0.5 to 1.5 dB in Es/No threshold — mean that the ACM system cannot always use the most efficient MODCOD available for the current link conditions. When the measured Es/No falls between two MODCOD thresholds, the system must fall back to the lower one, leaving unused capacity margin on the table.

No coverage below -2.35 dB Es/No. DVB-S2's lowest MODCOD (QPSK 1/4) requires approximately -2.35 dB Es/No, limiting the standard's ability to serve terminals with very small antennas, deep spot beams, or severely degraded link conditions.

No modulation above 32APSK. While 32APSK at code rate 9/10 delivers approximately 4.45 bit/s/Hz, clear-sky conditions on many HTS links can support higher-order modulation — capacity that DVB-S2 simply cannot exploit.

Roll-off floor at 0.20. Even the tightest DVB-S2 roll-off leaves 20% excess bandwidth beyond the Nyquist minimum, representing spectrum that could be recovered with sharper filtering.

These limitations — individually small but collectively significant — motivated the development of DVB-S2X.

---

What Is DVB-S2X?

DVB-S2X (ETSI EN 302 307-2), published in 2014, is a backward-compatible extension of DVB-S2 that addresses the limitations described above. It is not a replacement for DVB-S2 but rather a superset that adds new capabilities while maintaining interoperability with existing DVB-S2 equipment for the original 28 MODCODs.

The key additions in DVB-S2X include:

116+ MODCODs. DVB-S2X defines over 116 modulation and coding combinations, compared to DVB-S2's 28. The new MODCODs fill the gaps between existing DVB-S2 operating points and extend the range in both directions — lower SNR and higher spectral efficiency. This expansion includes normal frame and short frame variants, providing flexibility for different latency and carrier size requirements.

256APSK modulation. DVB-S2X introduces 256APSK as the highest-order modulation, extending peak spectral efficiency to approximately 5.1 bit/s/Hz under clear-sky, high-SNR conditions. This represents a roughly 15% improvement over DVB-S2's maximum of 4.45 bit/s/Hz with 32APSK 9/10.

Very Low SNR (VL-SNR) MODCODs. A set of new MODCODs designed for operation at Es/No values as low as -10 dB extends the standard's reach to terminals with very small antennas (sub-60 cm), deep spot beams with limited EIRP, and scenarios with high atmospheric or interference impairments. These VL-SNR modes use QPSK and BPSK-like modulations with very low code rates and specialized frame structures.

Tighter roll-off factors. DVB-S2X adds α = 0.10 and α = 0.15 to the existing 0.20, 0.25, and 0.35 options. The 0.10 roll-off reduces the occupied bandwidth of a carrier by approximately 8.3% compared to 0.20 roll-off, enabling tighter carrier packing on bandwidth-constrained transponders.

Wideband carrier support. DVB-S2X supports carrier bandwidths up to 500 MHz, compared to the practical limit of approximately 72 MHz for DVB-S2. This enables a single carrier to span an entire wideband transponder on modern HTS satellites, reducing the overhead of multiple-carrier configurations.

Channel bonding. DVB-S2X introduces the ability to aggregate multiple carriers from different transponders or frequency bands into a single logical channel, increasing the total throughput available to a terminal beyond what a single transponder can provide.

Super-frame structure. DVB-S2X defines a new super-frame format that improves synchronization, pilot insertion, and multiplexing efficiency for broadband interactive applications. The super-frame structure is particularly relevant for multi-carrier and wideband operations.

---

Key Technical Improvements in DVB-S2X

Finer MODCOD Granularity

The most impactful improvement in DVB-S2X for ACM-operated networks is the dramatically finer MODCOD granularity. DVB-S2 MODCODs are spaced 0.5–1.5 dB apart in their Es/No thresholds. DVB-S2X reduces this spacing to 0.2–0.5 dB across most of the operating range.

Why does this matter? In an ACM system, the MODCOD selected at any given moment is the most efficient one whose Es/No threshold is at or below the current measured signal quality (minus guard margin). When the gap between adjacent MODCODs is large, the system frequently operates with significant unused margin — the link could support a more efficient MODCOD, but none exists between the current selection and the next higher option.

Consider a concrete example. A DVB-S2 link measures 11.5 dB Es/No. The nearest DVB-S2 MODCOD below this threshold might be 8PSK 3/4 (threshold ~10.7 dB, spectral efficiency ~2.23 bit/s/Hz), while the next higher MODCOD is 16APSK 2/3 (threshold ~12.0 dB). The system uses 8PSK 3/4, leaving approximately 0.8 dB of margin unused. With DVB-S2X's finer granularity, there may be one or two intermediate MODCODs available in that gap — for example, a MODCOD with a threshold near 11.2 dB and spectral efficiency of ~2.45 bit/s/Hz. That is a 10% efficiency improvement for the same link conditions, achieved purely through finer waveform granularity.

Across an entire network with hundreds or thousands of terminals experiencing diverse and time-varying link conditions, these incremental gains at each operating point compound into a meaningful improvement in aggregate throughput — typically 5–15% depending on the distribution of link conditions and fade statistics.

Extended Operating Range

DVB-S2X extends the useful operating range of the standard in both directions.

At the low end, VL-SNR MODCODs enable operation down to approximately -10 dB Es/No. These modes use QPSK with very low code rates (down to 2/9 and below) and specialized spreading and pilot patterns optimized for reliable frame detection and synchronization at extremely low signal levels. The spectral efficiency at these operating points is low — in the range of 0.1–0.3 bit/s/Hz — but the ability to maintain a link at all under such conditions is valuable for mobile terminals, deep spot beams, and disaster recovery scenarios where any connectivity is better than none.

At the high end, 64APSK and 256APSK modulations extend peak spectral efficiency beyond DVB-S2's 32APSK ceiling. Under clear-sky conditions with high-gain antennas and benign propagation, 256APSK with high code rates achieves approximately 5.1 bit/s/Hz — roughly 15% more than DVB-S2's best case. This improvement matters most on high-throughput links where the link budget provides consistently high Es/No, such as feeder links, broadcast contribution links, and gateway-to-hub segments.

The combination of these extensions gives DVB-S2X an ACM dynamic range exceeding 25 dB — from -10 dB Es/No at VL-SNR to over 16 dB Es/No at the highest MODCODs — compared to approximately 18 dB for DVB-S2. This wider range is particularly valuable for ACM operation in Ka-band networks where rain fade events can produce 10+ dB of attenuation.

Roll-Off Factor Improvements

The roll-off factor α determines the excess bandwidth of a digitally modulated carrier beyond the theoretical Nyquist minimum. The occupied bandwidth (OBW) of a carrier is:

OBW = Symbol Rate × (1 + α)

For a 10 Msps carrier, the occupied bandwidth at different roll-off values is:

Moving from DVB-S2's tightest roll-off (0.20) to DVB-S2X's tightest (0.10) saves approximately 8.3% of occupied bandwidth per carrier. On a 36 MHz transponder carrying multiple carriers, this saving can free up enough spectrum to accommodate an additional carrier or increase the symbol rate of existing carriers.

However, tighter roll-off requires sharper filtering in both the transmitter and receiver, which increases implementation complexity and can introduce passband distortion if the filters are not well-designed. The transponder's own filtering characteristics also constrain how tight a roll-off is practical — if the transponder's passband shape does not accommodate the carrier's spectral edges cleanly, the effective benefit of tighter roll-off is reduced by the distortion introduced.

Wideband and Channel Bonding

DVB-S2X supports single carriers up to 500 MHz in bandwidth, aligned with the trend toward wideband transponders on modern HTS satellites. Satellites like the ViaSat-3 and Eutelsat KONNECT VHTS series employ transponders significantly wider than the traditional 36 MHz or 54 MHz segments used in conventional FSS satellites.

A single wideband carrier eliminates the overhead associated with guard bands, carrier spacing, and independent synchronization of multiple narrower carriers sharing the same transponder. For a transponder carrying four 72 MHz carriers, the guard bands and spectral gaps between carriers might waste 5–10% of the total transponder bandwidth. A single wideband carrier spanning the entire transponder recovers this wasted spectrum.

Channel bonding extends this concept further by allowing a terminal to simultaneously receive and combine carriers from different transponders, different frequency bands, or even different satellites. This aggregation increases the total available throughput to the terminal without requiring a single transponder wide enough to carry the entire capacity. Channel bonding is conceptually similar to carrier aggregation in LTE cellular networks and addresses the same fundamental challenge: providing high aggregate data rates when individual RF channels are bandwidth-limited.

---

Why DVB-S2X Matters in Real Networks

HTS and VHTS Broadband

High-throughput satellites using dozens or hundreds of spot beams represent the primary deployment target for DVB-S2X. In an HTS network, the forward link from the gateway to each terminal is ACM-operated, and the large number of terminals across diverse geographic and climatic zones means that the link condition distribution is broad and continuous. DVB-S2X's finer MODCOD granularity delivers its greatest value in this environment, because the average unused margin per terminal is minimized across the entire population.

The VL-SNR modes are also particularly relevant for HTS consumer broadband, where operators want to serve customers with small, self-installed antennas (60 cm or smaller) that may have marginal link budgets. Rather than excluding these customers or requiring expensive antenna upgrades, DVB-S2X's low-SNR capability allows the network to maintain service — albeit at reduced throughput — even when the link is severely impaired.

Backhaul and Enterprise

Point-to-point satellite backhaul links for cellular towers, enterprise VSAT networks, and government communications typically operate with fixed or semi-fixed antenna installations and stable link budgets. On these links, DVB-S2X's tighter roll-off factors and wideband carrier support deliver the most value. A cellular backhaul link operating at 0.10 roll-off instead of 0.20 frees up bandwidth on the transponder that can be allocated to additional backhaul customers or used to increase the data rate of existing links.

For enterprise networks using spectrum reuse across multiple beams, DVB-S2X's improved spectral efficiency at every operating point translates directly into more aggregate capacity from the same satellite resource.

Broadcast and Contribution

Television broadcast distribution and contribution links typically operate in CCM (constant coding and modulation) mode with fixed link budgets designed for high availability. In this context, DVB-S2X's 64APSK and 256APSK modulations provide the most benefit — the consistently high Es/No on well-engineered broadcast links can support these higher-order modulations, delivering more bits per hertz and allowing operators to fit more program channels into the same transponder bandwidth.

The tighter roll-off factors also benefit broadcast applications. A broadcast multiplier carrying 8–12 TV channels on a 36 MHz transponder can use the bandwidth saved by moving from 0.20 to 0.10 roll-off to add another channel or improve the video quality of existing channels through higher bit rates.

Capacity-Constrained and Mobile

In spectrum-constrained environments — military communications operating under strict frequency assignments, mobile platforms with limited antenna aperture, or networks operating in congested frequency bands — DVB-S2X's combination of finer MODCODs, tighter roll-off, and VL-SNR modes provides tools to extract maximum utility from every available hertz of spectrum.

For mobile satellite terminals on aircraft, ships, and vehicles, DVB-S2X's wide ACM dynamic range accommodates the rapid signal quality variations caused by platform motion, antenna tracking errors, and changing propagation conditions. The finer MODCOD granularity ensures that the ACM system can closely track these variations without large efficiency steps.

---

DVB-S2 vs DVB-S2X

The following table summarizes the key differences between DVB-S2 and DVB-S2X:

---

Practical Trade-Offs

DVB-S2X delivers real efficiency improvements, but those improvements are context-dependent and come with practical considerations that engineers must evaluate for each deployment.

Gains are incremental, not transformative. DVB-S2X does not deliver the 2× efficiency jump that DVB-S2 achieved over DVB-S. The improvements are in the range of 5–20% depending on the specific network configuration, link condition distribution, and which DVB-S2X features are utilized. For networks that are already well-optimized with DVB-S2 ACM, the incremental gain from DVB-S2X may be modest. For networks operating at the edges of DVB-S2's capability — very high SNR or very low SNR — the gains are more pronounced.

Modem compatibility. DVB-S2X requires modem hardware and software that supports the extended standard. Not all DVB-S2 modems can be upgraded to support DVB-S2X — the wider MODCOD table, higher-order modulation, and new frame structures may require hardware changes to the demodulator, FEC decoder, or baseband processing. Organizations planning a DVB-S2X deployment must verify that both hub-side and remote-side modems support the specific DVB-S2X features they intend to use.

Mixed DVB-S2/S2X operation. In networks with a mix of legacy DVB-S2 terminals and newer DVB-S2X terminals, the hub must manage both populations simultaneously. The DVB-S2 terminals can only use the original 28 MODCODs, while DVB-S2X terminals can access the extended set. This mixed operation is supported by the backward compatibility of the standard, but it adds complexity to carrier planning and capacity management. The full benefits of DVB-S2X are only realized when all terminals in a carrier are DVB-S2X-capable.

Cost versus incremental gain. The cost of upgrading to DVB-S2X-capable equipment must be justified by the efficiency gains it delivers. For a small network with a few terminals, the cost of new modems may not be offset by the bandwidth savings. For large HTS networks with thousands of terminals and significant transponder lease costs, even a 10% efficiency improvement translates to substantial annual savings. The business case depends on scale, transponder costs, and the specific link conditions of the network.

---

Engineering Considerations

Link Margin and MODCOD Selection

DVB-S2X's finer MODCOD granularity changes the link budget optimization process. With DVB-S2, the relatively large gaps between MODCODs meant that link budgets were often designed with a specific target MODCOD in mind, and the margin above that MODCOD's threshold was essentially wasted capacity. With DVB-S2X, the finer steps allow the link engineer to design for a tighter margin, knowing that intermediate MODCODs are available to exploit any excess Es/No.

In practice, this means that DVB-S2X link budgets can be designed with less clear-sky margin without sacrificing availability, because the ACM system can step down in smaller increments when conditions degrade. The result is higher average spectral efficiency across the entire availability range.

ACM Interaction

DVB-S2X's expanded MODCOD table interacts directly with ACM loop design. The finer granularity means more frequent MODCOD transitions, which places higher demands on the ACM loop's measurement accuracy, hysteresis design, and transition timing. If the ACM loop's Es/No measurement accuracy is ±0.5 dB — acceptable for DVB-S2's coarser steps — it may be insufficient for DVB-S2X's 0.2–0.3 dB steps, causing oscillation between adjacent MODCODs.

Modern DVB-S2X implementations address this with tighter Es/No estimation (±0.2–0.3 dB accuracy), carefully tuned hysteresis bands, and adaptive guard margins that account for the measurement uncertainty. The ACM loop design must be co-optimized with the DVB-S2X MODCOD table to realize the full benefit of finer granularity without introducing instability.

Carrier Planning and Spectral Efficiency

The tighter roll-off factors and wideband capabilities of DVB-S2X require updated carrier planning approaches. When using 0.10 roll-off, the carrier's spectral edges are sharper, which allows carriers to be packed more tightly but also makes the link more sensitive to frequency errors, Doppler shifts, and transponder filter characteristics.

Carrier planners must verify that the transponder's input and output multiplexer (IMUX/OMUX) passband shape is compatible with the intended roll-off and carrier placement. A transponder designed for 0.25 roll-off carriers may introduce excessive distortion at the edges of 0.10 roll-off carriers, negating the bandwidth savings.

For wideband carriers, the transponder's amplitude and group delay flatness across the full carrier bandwidth becomes critical. Amplitude ripple and group delay variation across a 500 MHz carrier are substantially greater than across a 36 MHz carrier, and the equalizer in the receiver must be capable of compensating for these impairments.

---

Common Misunderstandings

"DVB-S2X always means higher speeds." DVB-S2X improves spectral efficiency, not absolute data rates. The actual throughput of a link depends on the allocated bandwidth, link budget, and operating conditions. A DVB-S2X link using a narrow carrier under poor conditions may deliver lower throughput than a DVB-S2 link with a wider carrier under good conditions. The standard improves efficiency at each operating point, but efficiency is only one factor in the throughput equation.

"DVB-S2X is a software-only upgrade." While some DVB-S2 modems can add DVB-S2X support through firmware updates (particularly for the finer MODCODs and new roll-off factors), many DVB-S2X features — especially 256APSK demodulation, VL-SNR modes, and wideband carrier processing — require hardware changes. The LDPC decoder must handle new code lengths and rates, the demodulator must support higher-order constellations, and the ADC and digital processing chain must accommodate wider bandwidths. Verify upgrade paths with the modem vendor before assuming software-only migration.

"DVB-S2X replaces DVB-S2." DVB-S2X is an extension, not a replacement. DVB-S2 remains fully valid, widely deployed, and sufficient for many applications. The original 28 DVB-S2 MODCODs are part of the DVB-S2X standard, and DVB-S2X receivers are required to support them. Networks do not need to migrate away from DVB-S2 unless they have a specific operational or commercial need for the extended capabilities. Many networks will operate with mixed DVB-S2/S2X populations for years.

---

Frequently Asked Questions

What is the main difference between DVB-S2 and DVB-S2X?

DVB-S2X extends DVB-S2 with over 116 MODCODs (vs 28), finer granularity between them (0.2–0.5 dB steps vs 0.5–1.5 dB), additional roll-off factors (0.10 and 0.15), higher-order modulation (up to 256APSK), VL-SNR modes for operation down to -10 dB Es/No, wideband carriers up to 500 MHz, and channel bonding capability. These extensions improve spectral efficiency by 5–20% depending on operating conditions.

Is DVB-S2X backward compatible with DVB-S2?

Yes. DVB-S2X maintains full backward compatibility with DVB-S2's 28 MODCODs and frame structure. A DVB-S2X-capable receiver can demodulate DVB-S2 transmissions, and a DVB-S2 receiver can operate on a carrier that also serves DVB-S2X terminals (using only the DVB-S2 subset of MODCODs). The extended MODCODs and features are additive, not replacements.

How much efficiency improvement does DVB-S2X provide over DVB-S2?

The efficiency gain depends on the specific operating scenario. In ACM-operated broadband networks, the finer MODCOD granularity typically provides 5–15% improvement in average spectral efficiency. At the high-SNR end, 256APSK extends peak efficiency by approximately 15% over DVB-S2's 32APSK maximum. At the low-SNR end, VL-SNR modes extend operability into conditions where DVB-S2 cannot function at all. Combined with tighter roll-off savings, total system-level gains of 10–20% are achievable.

Do I need new hardware for DVB-S2X?

It depends on which DVB-S2X features you need. Some DVB-S2 modems support finer MODCODs and additional roll-off factors through firmware upgrades. However, 256APSK demodulation, VL-SNR modes, wideband carrier processing, and channel bonding typically require hardware that was designed for DVB-S2X from the start. Check with your modem vendor for specific upgrade paths.

What is VL-SNR and why does it matter?

VL-SNR (Very Low Signal-to-Noise Ratio) refers to a set of DVB-S2X MODCODs designed for operation at Es/No values as low as -10 dB. These modes enable satellite links to function with very small antennas, deep spot beams, or severely degraded conditions. While throughput at VL-SNR operating points is low, the ability to maintain connectivity under extreme conditions is valuable for mobile, maritime, and emergency communication scenarios.

How does the 0.10 roll-off factor help?

A roll-off factor of 0.10 reduces the occupied bandwidth of a carrier by approximately 8.3% compared to DVB-S2's minimum roll-off of 0.20. For a carrier with a 10 Msps symbol rate, this means occupying 11.0 MHz instead of 12.0 MHz. On a transponder carrying multiple carriers, this saving can free up enough bandwidth to accommodate additional carriers or increase symbol rates. The trade-off is more demanding filter requirements in the transmitter, receiver, and transponder.

Is DVB-S2X used on LEO satellites?

DVB-S2X's features are applicable to LEO systems, particularly the VL-SNR modes (useful during low-elevation passes with longer path lengths) and the wide ACM dynamic range (valuable for the continuously changing link geometry). However, LEO constellations like Starlink and OneWeb use proprietary waveforms optimized for their specific system architectures rather than DVB-S2X. GEO-based HTS networks remain the primary deployment environment for DVB-S2X.

When should I consider upgrading from DVB-S2 to DVB-S2X?

Consider upgrading when: (1) transponder costs are a significant portion of your operating budget and even 10% efficiency gains justify the investment; (2) you operate in Ka-band or other bands with high fade variability where finer ACM granularity delivers measurable throughput gains; (3) you need to serve terminals with small antennas that benefit from VL-SNR modes; (4) you are deploying new equipment and can choose DVB-S2X-native modems at marginal incremental cost over DVB-S2-only modems; or (5) you are planning wideband operations on next-generation HTS transponders that exceed DVB-S2's practical carrier bandwidth limits.

---

Key Takeaways

• DVB-S2X is an extension, not a replacement — it adds 116+ MODCODs, 256APSK, VL-SNR modes, tighter roll-off, and wideband support while maintaining full backward compatibility with DVB-S2.

• Finer MODCOD granularity is the biggest practical benefit — 0.2–0.5 dB steps between MODCODs reduce the average unused margin in ACM networks, delivering 5–15% improvement in aggregate spectral efficiency.

• Roll-off improvements save real bandwidth — moving from 0.20 to 0.10 roll-off frees approximately 8.3% of occupied bandwidth per carrier, enabling tighter carrier packing on congested transponders.

• VL-SNR extends connectivity, not speed — operating down to -10 dB Es/No enables links that DVB-S2 cannot support at all, valuable for small terminals, mobile platforms, and emergency communications.

• Gains are incremental and context-dependent — DVB-S2X typically delivers 10–20% system-level efficiency improvement, not the 2× leap that DVB-S2 achieved over DVB-S. The business case depends on scale, transponder costs, and specific network requirements.

• Mixed DVB-S2/S2X operation is the norm — most networks will operate with both DVB-S2 and DVB-S2X terminals during the transition period, and the backward-compatible design supports this coexistence.

---
